The Z-Bar Rise Square is a tiered addition to the Z-Bar Pendant series. Available in 3 sizes, this sculptural pendant features modular light bars that independently rotate 360.°
Product Features:
- Collection: Z-Bar
- Designer: Kenneth Ng, Edmund Ng
- Country of Origin: China
- Warranty: 5 years; 1 year for the LED driver specifically.
- Award:
- Best of NeoCon GOLD 2016 (Z-Bar Pendant series)
- If Design Award 2017 (Z-Bar Pendant series)
- Red Dot Design Award 2017
- Light bars on the top tier, bottom tier and sides (for 16-Inch, 24-Inch, 48-Inch); Light bars on the top tier and bottom tier (for 38-Inch, 54-Inch)
- Compatible with many ELV dimmers. Visit koncept.com/dimmers to download a dimmer compatibility chart.
- Ambient light and direct light can be achieved at the same time with 2 layers of light
- Special Features:
- Some Assembly Required
- Available in various light bar lengths and finishes
Dimensions:
- 16-Inch: 18"W X 16.75"H
- Canopy: 12"D X 1.1"H
Product Weight: 6.44 lbs
- 24-Inch: 26"W X 22"H
- Canopy: 12"D X 1.1"H
Product Weight: 7.54 lbs
- 48-Inch: 50.5"W X 19.5"H
- Canopy: 12"D X 1.1"H
Product Weight: 12.59 lbs
- 38-Inch: 40"W X 11.6"H
- Canopy: 23.1"W X 1.2"H
Product Weight: 6.37 lbs
- 54-Inch: 56.2"W X 11.6"H
- Canopy: 23.1"W X 1.2"H
Product Weight: 7.69 lbs
Lamping:
- 16-Inch: 1 X 40W 120V integrated LED module; 2100 lumens, 90 CRI, 3000K (included)
- 24-Inch: 1 X 40W 120V integrated LED module; 3000 lumens, 90 CRI, 3000K (included)
- 48-Inch: 1 X 140W 120V integrated LED module; 8900 lumens, 90 CRI, 3000K (included)
- 38-Inch: 1 X 40W 120V integrated LED module; 3000 lumens, 90 CRI, 3000K (included)
- 54-Inch: 1 X 84W 120V integrated LED module; 5350 lumens, 90 CRI, 3000K (included)
Ratings:
- Listing: UL Listed, cUL Listed
Materials:
- Aluminum, zinc alloy, plastic
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
